HDPE Compression Fittings, PP compression fittings, HDPE Compression Female Tee, Compression Female Tee, HDPE female Tee, Poly Female Tee, PP Compression Female Tee, HDPE pipe Female Tee

A HDPE compression female tee is used to tee off a length of metric HDPE pipe with a male threaded pipe offtake. This is often used to fit a male-threaded valve or tap via compression fitting, to a HDPE pipeline. PP Compression female tee fittings are often used for irrigation and hydroponics, as they can fit a valve/tap right next to the main pipeline, to adjust flow to the off-take pipeline.

HDPE female tee compression can be manufactured in a diameter sizing from 20*1/2”*20mm to 110*4”*110mm, with pressures up to 16 bar.

SUNPLAST PP Compression Fittings range have a heterophasic black polypropylene body suitable at high temperatures, with a polyacetal resin clinching ring and a blue dyed PP nut offering suitability to UV rays and system heat. These fittings also use an acrylonitrile rubber or lip seal gasket, based on the different fitting diameters.

PP compression female tee fittings are consisted of 5 plastic accessories:

More brief details as below:

Product Specifications

HDPE/PP compression female tee fittings can be manufactured sizing from 20*1/2”*20 mm to 110*4”*110 mm. The size 20-63mm with a pressure of PN16, and 75-110mm pressurized in PN10.

Benefits Of HDPE Compression Fittings

There are multiple benefits to using HDPE compression fittings in your piping systems. Some of the main advantages include:

Easy to assemble and disassemble without the need for special tools

Low maintenance over time, which makes the piping system last longer

No soldering required, which is especially beneficial for areas where no soldering is allowed

Light-weight in comparison to other materials, which assists in making the assembly quick and more effective

Leak-free jointing is ensured via heat-infused joints to ensure strong connections

Leak-free connections, provided they are installed correctly

Corrosion resistant due to being HDPE. They won’t rust or disintegrate, even after continuous exposure to water or liquids

Can handle water surges due to excellent water hammer capabilities

Installation procedure For HDPE Compression Fittings

HDPE Pipe Compression fittings provide a a easy & simple installation for HDPE pipe without welding. It allows joining of pipe in a few easy steps. Simply cut, chamfer and clean the pipe, loosen the compression nut on the fitting, insert the pipe into the fitting until it bottoms out, and mechanically tighten the nut. When properly completed, your new connection is immediately ready for pressure.

1. Pipe ends must be cut square and burr-free before using with the fittings. Chamfer

may be provided on the pipe end to facilitate ease of pipe insertion.

2. No need to open fitting & take apart components separately. Just loosen the QJN

(Quick Joint Nut) by three to four turns.

3. Insert the pipe into the fitting up to the stopper.

4. Hand Tighten the QJN for fittings up to 32 mm.

5. Use Wrench to tighten the QJN after hand tightening for fittings 40 mm and above.

6. After Firm Hand Tightening, Tighten the QJN with wrench only for a quarter turn.

Contact Us

If you have any requirements on PP compression fittings, or any question on our fittings, please contact us freely. SUNPLAST has well trained staff who are available to address your needs and provide technical support to all sectors when needed.
