Plastic Pipe PP Compression Quick Connect Reducer Adapter Fitting
Description
Technical Parameters
We take the responsibility of manufacturing fine Poly Female Thread Elbow, electrofusion fittings, Compression reducer and serving the society, and always adhere to the road of scientific and technological innovation and technological progress. We establish scientific and effective decision-making, operation and management mechanisms in accordance with the requirements of the modern enterprise system. 'Making the Products and solutions of Superior Quality' may be the eternal target of our company.
HDPE Compression Fittings, PP compression fittings, HDPE Compression Equal Tee, Compression tee, Poly Compression tee, Compression Tee fittings, HDPE compression tee, PP Compression Tee
A HDPE compression equal tee fitting is used to join three lengths of metric HDPE pipe in a T shape. As an equal tee fitting, all ends of the Tee are the same size.
PP compression tee fittings can be manufactured in a diameter sizing from 20mm to 110mm, with pressures up to 16 bar. The HDPE compression tee fittings are made from high quality PP-B material that is resistant to etching by numerous chemical substances, and to UV rays, and are suitable for outdoor use.
SUNPLAST HDPE compression fittings / PP compression fittings are manufactured in compliance with the requirements of standards EN 712/713/715/911; ISO 3501/3503/3458/3459.The fittings can be installed on HDPE pipes which are in compliance with standards ISO 11922; DIN 8072/8074; UNE 53131. The threaded versions are manufactured in compliance with standard ISO 7; DIN 2999.
PP compression tee fittings are consisted of 5 palstic accessories:
Mark | Part Name | Material | Color |
A | Cap | High quality polypropylene black co-polymer (PP-B) | Blue |
B | Clinching Ring | POM resin | White |
C | Blocking Bush | High quality polypropylene black co-polymer (PP-B) | Black |
D | "O" Ring Gasket | NBR rubber | Black |
E | Body | High quality polypropylene black co-polymer (PP-B) | Black |
More brief details as below:
Product | HDPE Compression Equal Tee, Compression tee, Poly Compression tee, Compression Tee fittings, HDPE compression tee, PP Compression Tee |
Specification | 20mm to 110mm |
Pressure ratings | Working Pressure at 20℃: 20~63mm in PN16; 75~110mm in PN10 |
Material | High quality polypropylene black co-polymer (PP-B) |
Color | Black body / Blue Cap |
Manufacturing Standard | Dimensions and characteristics: ISO 3501/3503/3458/3459. To be installed on HDPE pipes: ISO 11922; DIN 8072/8074; Threads (BSP): ISO 7; DIN 2999. |
Samples available | Yes, samples are available, but charged. |
Packing method | Cartons |
MOQ | Negotiable |
Customized Logo available (OEM Service) | For small quantity of order, customer logo can be marked on the fittings by laser marking or sticker. For big quantity of order, customer logo can be embossed on the fittings. |
Production lead time | Mass stock available for regular sizes About 10 days for a 20ft container, 20 days for a 40ft container |
Warranty time | 1 years for normal use |
Payment term | T/T, L/C, DP, Western Union, or negotiable |
FOB loading port | Ningbo/Shanghai China |
Place of origin | Ningbo, China |
Product Specifications
HDPE/PP compression tee fittings can be manufactured sizing from 20mm to 110mm. The size 20-63mm with a pressure of PN16, and 75-110mm pressurized in PN10.
Size (mm) | Pressure Rating (bar) | Weight (gram/PCS) | Packing (PCS/CTN) |
20 | PN16 | 111 | 140 |
25 | PN16 | 168 | 90 |
32 | PN16 | 251 | 52 |
40 | PN16 | 460 | 32 |
50 | PN16 | 748 | 18 |
63 | PN16 | 1350 | 9 |
75 | PN10 | 1663 | 6 |
90 | PN10 | 2383 | 4 |
110 | PN10 | 4238 | 2 |
HDPE Compression Fittings SUNPLAST Can Offer
As a integrated & experienced manufacturer & provider in China, SUNPLAST carries an extensive range of HDPE compression fittings in a diameter sizing from 20mm to 110mm, and all customers can find the best solution of fittings for their pipeline systems in SUNPLAST.
Our poly pipe compression fittings include:
→ HDPE Compression Coupler/Coupling,HDPE Compression Reducer Fittings, HDPE Compression Female/Male Adaptor Fittings
→ HDPE Compression 90 Degree Elbow,HDPE Compression Female/Male Elbow Fittings
→ HDPE Compression Equal Tee, HDPE Compression Reducing Tee, HDPE Compression Female/Male Tee Fittings
→ HDPE Compression Flange Adaptor
→ HDPE Compression tee
Manufacturing Facilities
SUNPLAST is a ISO9001 certificated manufacturing factory. As a premier manufacturer of HDPE compression fittings, the factory owns mature technology, advanced production machine, professional workers & completed QC system. All compression fittings are manufactured strictly in compliance with national standards and international standards.
Till now, there is over 10 sets of injection machines in SUNPLAST workshop, available to manufacture HDPE fittings till 800mm, and annual production capacity reaches 5,000 tons.
Why Choose Us?
☑ Rich experience on manufacturing HDPE fittings over 20 years, we are an expert in this industry.
☑ Full product range available, you will always find the right solution here.
☑ Strong after-sale term supports to provide professional guide for installation.
☑ By using top quality raw material, with long warranty time on quality.
☑ Short lead time to satisfy your urgent need request.
☑ Quick reply for your inquiries within 12 hours.
☑ OEM service available to support a good sale in customers' market.
Contact Us
If you have any requirements on PP compression fittings, or any question on our fittings, please contact us freely. SUNPLAST has well trained staff who are available to address your needs and provide technical support to all sectors when needed.
Single-mindedness and excellence are our core values. At a new starting point, we are willing to continue to make unremitting efforts for the development of Plastic Pipe PP Compression Quick Connect Reducer Adapter Fitting. Our corporate culture concept system with learning, surpassing and leading spirit is the driving force for the company's progress and development. The company sincerely welcomes domestic and foreign customers to visit our company, guide and conduct business negotiations, cooperation and investment matters.
Hot Tags: HDPE compression equal tee, China, suppliers, manufacturers, factory, buy, price, made in China, PVC Cross Fittings, uPVC Double Union Ball Valve, PP Compression Elbow, Poly pipe compression reducer, uPVC Flange Adaptor With Rubber Ring, poly flange adapter
